SWA 43RER | 4mm Insulated Ring Crimp Terminal For 0.5-1.5mm Cable, Red (Pack of 100)

SWA 43RER | 4mm Insulated Ring Crimp Terminal For 0.5-1.5mm Cable, Red (Pack of 100)

Part Number/SKU: 43RERCategory:

£2.45 ex VAT

£2.94 inc VAT

This item is currently out of stock.

SWA 43RER | 4mm Insulated Ring Crimp Terminal For 0.5-1.5mm Cable, Red (Pack of 100)

£2.45 ex VAT

£2.94 inc VAT

  • The SWA 43RER 4mm Insulated Ring Crimp Terminal For 0.5-1.5mm Cable is a pack of 100, red.
  • Applied onto a wire and crimped which is then often connected to another terminal or fixing.
  • The brazed seam barrels alongside the quality of the materials and manufacturing process provides consistent crimping performance.
  • Polyvinyl chloride insulated with easy and quick entry aperatures for quick cable insertion.

    • Additional information

    Current Rating (max)

    19 A
    Voltage (max)

    600 V
    Insulated

    Yes
    Terminal Material

    Copper
    Insulation Colour

    Red
    Cable Size Range

    22 to 16 AWG mm2
    Hole/Stud Size

    4.3 mm
    Insulation Material

    PVC
    Diameter

    1.8 mm
    Length Min Max

    16.2 mm
    Standards

    ROHS UL E100455 CSA
    no downloads/datasheets currently available.
