Hager WMP2FO | Sollysta 20A Flex Outlet Plate, White

Hager WMP2FO | Sollysta 20A Flex Outlet Plate, White

Part Number/SKU: WMP2FOCategory:

£3.43 ex VAT

£4.12 inc VAT

🚚 Delivery: Next working day if ordered by 4pm!

PLEASE NOTE:
This item is no longer manufactured / no longer stocked. The replacement is the Click Scolmore CMA017

Click here to view the replacement - Click Scolmore CMA017

Hager WMP2FO | Sollysta 20A Flex Outlet Plate, White

£3.43 ex VAT

£4.12 inc VAT

  • The Hager WMP2FO Sollysta 20A Flex Outlet Plate is a 1 gang mounting plate used for wiring appliances under a unit/worktop, connecting a fixed appliance to building wiring.
  • It has a glossy white urea finish and a sleek profile that nicely complements modern-day decor in domestic and commercial applications.
  • It is easy to install thanks to the shallow back projection offering increased cabling space.
  • The 20A Hager WMP2FO features 2 separate terminals for each Line, Neutral, and Earth so flexible and fixed wiring are not occupying the same terminal.
  • The flex outlet plate features a single screw fast fix cable clamp, M3.5 x 30mm long fixing screws and screw covers, and terminal capacities of 20A 2 x 6mm² and 45A 2 x 10mm² conductors.
  • It comes with loop terminals that allow neutral looping at the switch.
  • In addition, the twin socket comes with twin earth as standard, and double pole switching in the switched sockets.
  • The Hager WMP2FO can be wired either 1 way or 2 ways with clear terminal markings; L-1 for 1-way and L-2 for 2-way.
  • All terminal screws are grouped in-line and upward facing for an easy installation job.
  • It is advised that a protective red washer is used under the cable clamp to prevent damage to the cable.
  • The cable clamp accommodates up to a 1.5mm² flexible cord.
  • The flex outlet plate complies with BS 5733 standards.
  • Dimensions of H 86mm x L 86mm x W 27mm.

    • no downloads/datasheets currently available.
