Hager WMCC50 | Sollysta 45A Double Pole DP Cooker Control Switched Socket Outlet, White

Hager WMCC50 | Sollysta 45A Double Pole DP Cooker Control Switched Socket Outlet, White

Part Number/SKU: WMCC50Category:

£9.89 ex VAT

£11.87 inc VAT

🚚 Delivery: Next working day if ordered by 4pm!

PLEASE NOTE:
This item is no longer manufactured / no longer stocked. The replacement is the MK K5060WHI

Click here to view the replacement - MK K5060WHI

Hager WMCC50 | Sollysta 45A Double Pole DP Cooker Control Switched Socket Outlet, White

£9.89 ex VAT

£11.87 inc VAT

  • The Hager WMCC50 Sollysta 45A Double Pole DP Cooker Control Switched Socket Outlet is a 2 gang 45A flush-mounted cooker control unit with a switched socket and neon LED light indicators on both switches.
  • It is made from Urea-Formaldehyde and duroplastic.
  • It has a shallow depth and comes complete with moulded cable lead-ins, in-line terminals, wire end stops, and a unique neutral loop terminal.
  • The Hager WMCC50 also has a 3-pin operated shutter mechanism on the sockets which gives them an additional element of safety as it prevents access to live parts unless all 3 pins from a 45-amp plug are in position.
  • The switch and socket are double poled, with twin earth included as standard, while the main switch is suitable for isolation.
  • For easier installation, all the terminals are marked and upward facing, with the capacity of terminals measuring 2 x 6mm² and 1 x 16mm².
  • It also has backed-off screws held captive to prevent loss, wired end stops, and clearly visible white labelling off a dark grey background.
  • The wall switches are the first to have a neutral loop terminal contained within the application, allowing contractors to complete the loop connection in the switch rather than in the ceiling rose.
  • This also helps reduce cabling and uneasy time spent working at ceiling level.
  • It comes with M3.5 x 30mm long screw fixings supplied.
  • Its sleek, gloss white exterior and slim frame provide a clean and modern finish to any room whilst the white moulded range has a high impact strength and scratch resistance for safety.
  • With an Ingress Protection rating of IP20, the HAGER WMCC50 is touch-proof and resistant to dust ingress or objects that are over 12 mm in size.
  • It complies with BS 4177 standards and meets the needs of BS7671.
  • Dimensions of D 39.6mm x H 86mm x W146mm.

    • no downloads/datasheets currently available.
