Europa SISH324N | 400V 32A 3 Pole + E IP44 Horizontal Interlocked Socket, Red

£51.47 ex VAT

£61.76 inc VAT

  • The Europa SISH324N 400V 32A 3 Pole + E IP44 Horizontal Interlocked Socket is for use with a 400V AC supply and has a 2.5 to 10mm nominal cross section area giving it a 32Amp current rating.
  • It has 4 pins, 3 poled and earth and is manufactured from self-extinguishing & shock resistant thermoplastic.
  • It comes equipped with two cable inlets M25, M32 one top and bottom and Inox screws which are chemical agent resistant.
  • In addition, the socket has an ABS Enclosure and is pad-lockable in the On and Off positions for added security, as well as multiple knockouts for easier installation.
  • The Europa SISH324N is designed to provide a safe and frequent connection and disconnection through a mechanical interlock, with a high-quality plastic housing which is resistant to chemical and heavy-duty usage damage.
  • It is a popular choice for industrial installations such as in the chemical industry, airports, sawmills, and hospitals as it is also used to provide a connection to the electrical mains rated at higher voltage and current than household plugs and sockets.
  • It features a built-in switch disconnector, a PBT enclosure and clear terminal markings for improved safety and ease of operation.
  • As it is an interlocked socket, it has interlocking capabilities which helps ensure a safe operation.
  • For increased safety, it is recommended to regularly check all connections and terminals to ensure they have the correct tightness as loose terminals can cause overheating which can result in fire hazards or heat damage to the cable.
  • The Europa SISH324N is CE certified and made to IEC 60309-2 standards with an IP44 ingress protection rating, protecting the socket against dust ingress and solid particles over 1mm in size and from low pressure water particle exposure from any direction.

    • Additional information

    Current Rating

    32 A
    Voltage

    400 V
    Ingress Protection

    IP44
    no downloads/datasheets currently available.
