Europa IP325N | 415V 32A 3 Pole + N + E IP44 Industrial Mains Plug, Red

Part Number/SKU: IP325NCategory:

£6.39 ex VAT

£7.67 inc VAT

🚚 Delivery: Next working day if ordered by 4pm!

We only have 7 remaining! We are waiting for further stock.

Europa IP325N | 415V 32A 3 Pole + N + E IP44 Industrial Mains Plug, Red

£6.39 ex VAT

£7.67 inc VAT

  • The Europa IP325N 415V 3 Poled + N + E 32A IP44 Industrial Mains Plug is IP44 rated and has a 2.5mm to 6mm² cable cross sectional capacity, giving it a 32Amps current rating.
  • The industrial plug is 3 poled with Neutral and Earth, providing a connection to the electrical mains which has a higher current and voltage rating than household plugs and sockets.
  • It provides users with an easy to install and highly reliable plug which is suited for extreme conditions.
  • The Europa IP325N is constructed from thermoplastic self-extinguishing material, giving it a high-quality housing.
  • It is designed to be cable mounted with a suitable cable or panel mounted socket.
  • In addition, the plug comes with a pre-prepared cable clamp and an open cable gland which ensures fast and easy wiring.
  • It also has a quick releasing robust casing which does not require screwing and is designed to ensure the long life and reliability of the ongoing performance.
  • The Europa IP325N has open terminals with backed out screws ensuring an easy installation process.
  • The industrial mains plug is CE certified and made to IEC 60309 standards with an IP44 ingress protection rating which means the plug is protected against low pressure water sprays from any direction, and dust ingress and solid particles over 1mm in size.
  • Dimensions of 150mm x 79mm x 50mm with a 2.5mm to 6mm² cable nominal cross section area.

    • Additional information

    Current Rating

    32 A
    Voltage

    415 V
    Ingress Protection

    IP44
    no downloads/datasheets currently available.
