Eaton EMCH140 | Memshield3 40A 10kA/15kA Single Pole C Curve MCB

Name: Eaton EMCH140 | Memshield3 40A 10kA/15kA Single Pole C Curve MCB
Brand: Eaton
SKU: EMCH140
Price: 14.82 GBP
Availability: InStock

Part Number/SKU: EMCH140Category: Eaton MCBs

£12.35 ex VAT

£14.82 inc VAT

🚚 Delivery: Next working day if ordered by 4pm!

We only have 1 remaining! We are waiting for further stock.

The Eaton EMCH140 Memshield3 40A 10kA/15kA Single Pole C Curve MCB is a high-performing, DIN rail mountable, outgoing current-limiting device, also known as a miniature circuit breaker and can disconnect short circuits.

It is designed to detect any overcurrents from overload and fault currents and then interrupt the current flow to safely protect your electrical power distribution systems in commercial and industrial applications.

The Eaton EMCH140 has a 40A current rating, 415V voltage rating, 10kA and 15kA short-circuit breaking capacity to IEC 60898 and IEC 60947-2 respectively, and a trip Type C curve.

In addition, it comes complete with ‘On and Off’ indicators that indicate what position the MCB is in; box clamp terminals that accept cables up to 25mm²; a positive contact flag indicator, and a box clamp barrier to prevent any incorrect cable/busbar insertion.

It can also be used with pin and comb type busbars and is suitable for use in Eaton Memshield 3 distribution boards and appliances.

It also has an IP20 ingress protection rating ensuring protection against dust and solid particles greater than 12mm.

Dimensions of H 80mm x W 18mm x D 60mm.

Additional information

Product	Circuit Breaker
Product Type	MCB
Pole Configuration	SP
Mounting	DIN Rail
Ingress Protection	IP20
Trip Type	Type C
Short Circuit Rating	10/15 kA
Height	80 mm
Width	18 mm
Depth	60 mm
Current Rating	40 A
Voltage	230\|240 V
Standards	IEC/EN 60898 IEC/EN 60947-2
